Specifications
- Platform: Linux + ARM + FPGA
- Monitor: 15-inch LCD, 1024×768 resolution
- Battery: Built-in lithium battery, ≥1 hour continuous use
- Storage: 500GB internal hard disk
- Probe Ports: 4 universal ports (3 active), 156-pin
- Supported Formats: BMP, JPG, FRM, CIN, AVI, DICOM 3.0
- Image Modes: B, M, Color, PDI,TDI, PW, CW,Dual/Quad View
- Zoom: Up to 10x
- Cine Memory: B: ≥5000 frames; Color/PDI: ≥2300 frames; M/PW: ≥190s
- Languages: EN, CN, ES, FR, DE, RU, CZ + customizable
- I/O Ports: USB ×2, HDMI, LAN, ECG out, video, S-Video
Key Features
- Trolley-based system with 4 transducer ports for multi-probe workflows
- DICOM-compliant imaging with 500GB internal data management
- High-resolution display with wide angle view and intuitive controls
- Supports dual real-time imaging, Doppler, and harmonic imaging
- Compatible with over 9 types of probes for general and specialty applications
- Real-time cine loop with large frame buffer for review
- USB mouse and printer support, USB image export
- Waterproof, backlit ergonomic control panel with centralized trackball
- One-touch image parameter save and restore function
- Multi-language interface with customizable exam presets
- OEM/ODM Ready: Customizable brand, appearance, and features
Standard Configuration
- Main Unit (with 500GB HDD)
- 3C6C Convex probe
- 7L4C Linear probe
- Power Cable
- User Manual
Optional Accessories
- 6E1C Endocavity Convex probe
- 10L25C Linear probe
- 6I7C Intrarectal Linear probe
- 6C15C, 3C20C Micro convex probes
- 2P2F 、5P2F、7P1F Phased array probes
- USB printer / B/W / color Video printer
- Puncture rack
- foot switch
- U disk and USB extension cable
Dimensions and Weight
- Machine Size: 650mm (front-back) × 580mm (left-right) × 1320mm (height)
- Machine Weight: 29.5 kg (excluding probes)
- Package Size: 750mm × 700mm × 1190mm
- Total Weight (incl. 2 probes and wooden box): 52 kg
