Specifications
- Platform: Linux + ARM + FPGA
- Monitor: 15-inch LCD, 1024×768 resolution
- Battery: Built-in lithium battery, ≥1 hours continuous use
- Storage: 500GB internal hard disk
- Probe Ports: 2 active universal ports, 156-pin
- Supported Formats: BMP, JPG, FRM, CIN, AVI, DICOM 3.0
- Image Modes: B, M, Color, PDI,TDI, PW, CW,Dual/Quad View
- Zoom: Up to 10x
- Cine Memory: B: ≥5000 frames; Color/PDI: ≥2300 frames; M/PW: ≥190s
- Languages: EN, CN, ES, FR, DE, RU, CZ + customizable
- I/O Ports: USB ×2, HDMI, LAN, ECG out, video, S-Video
Key Features
- Dual-mode ultrasound system for human and veterinary diagnostics
- Advanced Doppler imaging modes: PW, CW, PDI,TDI, Color Flow Mapping
- 15" high-resolution wide-angle display with ergonomic layout
- 500GB internal HDD with built-in DICOM-compliant workstation
- Compound imaging, speckle reduction, IMT, LITO, B/BC dual real-time imaging
- Multilingual user interface and customizable exam presets
- Extended battery life for mobile/field operations
- Backlit, waterproof control panel for clinical use
- Fast image parameter save/restore with one-key operation
- Clear Imaging & High Cost-Performance: Perfect for primary healthcare
- OEM/ODM Ready: Customizable brand, appearance, and features
Standard Configuration
- Main Unit (with 500GB HDD)
- 3C6C Convex probe
- 7L4C Linear probe
- Power Cable
- User Manual
Optional Accessories
- 6E1C Endocavity Convex probe
- 6I7C Intrarectal Linear probe
- 6C15C, 3C20C Micro convex probes
- 2P2F, 5P2F ,7P1F Phased array probes
- USB printer / B/W / color Video printer
- Puncture rack
- Trolley
- Foot switch
- U disk and USB extension cable
Dimensions and Weight
- Machine Size: 370mm (W) × 360mm (H) × 150mm (T)
- Machine Weight: 8.4 kg
- Package Size: 460mm × 460mm × 310mm
- Package Weight: 12 kg (incl. 2 probes and packing materials)
