Specifications
- Platform: Linux + ARM + FPGA
- Monitor: 15-inch LCD, 1024×768, wide angle, progressive scan
- Battery: Built-in lithium, ≥1 hour use
- Storage: Internal 128GB internal hard disk
- Probe Ports: 2
- Supported Probes: Convex, Linear, Endocavity, Micro-convex
- Imaging Modes: B, M, Color, PDI,TDI, PW, Dual/Quad View
- Zoom: Up to 10×
- Image Save Format: BMP, JPG, FRM, CIN, AVI, DICOM 3.0 compliant,built-in workstation
- Cine Memory: B: ≥5000 frames; Color/PDI: ≥2300 frames; M/PW: ≥190s
- Languages: EN, CN, ES, FR, DE, RU, CZ + customizable
- Ports: USB×2 (rear), supports mouse, printer, LAN
Key Features
- Dual-mode presets for human and veterinary applications
- Fast startup (≤12 seconds) with intuitive UI
- Supports harmonic imaging, compound imaging, and speckle reduction
- Multilingual user interface and customizable exam presets
- Clear Imaging & High Cost-Performance: Perfect for primary healthcare
- OEM/ODM Ready: Customizable brand, appearance, and features
Standard Configuration
- Main unit (with 128GB SSD)
- 3C6A Convex probe
- 7L4A Linear probe
- Power adapter
- Power cable
- User manual
Optional Accessories
- 6E1A EndocavityConvex probe
- 6C15A Micro convex probe
- 6I7A Intrarectal Linear probe
- USB report printer
- B/W or color Video printer
- Puncture rack
- Trolley
- foot switch
Dimensions and weight
- Host: size：370mm (width) * 350mm(depth) * 70mm(thickness)
- weight: 5.5kg(with no probe)
- Including package:Size: 465mm(width) ×465mm(depth) × 230mm(thickness)
- weight: 9.5kg(host + 2 probes + power cable + adapter + manual + carton + foam)
