Specifications

- Platform: Linux + ARM + FPGA, low power and stable
- Monitor: 15-inch LCD, 1024×768, wide viewing angle
- Weight: 5.5 kg (host only); 9.5 kg with package
- Battery: ≥1 hours continuous use
- Storage: 500GB internal hard disk
- Probe Ports: 2 active universal ports, 160-pin
- Imaging Modes: B, M, Color, PDI,TDI, PW, CW,Dual/Quad View
- Zoom: Up to 10x
- Cine Memory: B: ≥5000 frames, Color/PDI: ≥2300 frames, M/PW: ≥190s
- Languages: EN, CN, ES, FR, DE, RU, CZ + customizable
- I/O Ports: USB ×2,  LAN,  video, S-Video
- Supported Formats: BMP, JPG, FRM, CIN, AVI, DICOM 3.0

Key Features

- Dual-mode system for human and veterinary applications
- Real-time dual imaging (B/BC) and advanced Doppler modes
- Built-in 500GB hard disk for long-term patient data storage
- Integrated workstation with DICOM 3.0 compatibility
- Multilingual user interface and customizable exam presets
- Clear Imaging & High Cost-Performance: Perfect for primary healthcare
- OEM/ODM Ready: Customizable brand, appearance, and features

Standard Configuration

- Host(Built-in 500G hard disk)
- 3C6C Convex probe
- 7L4C Linear probe
- Power adapter
- Power cable
- User manual

Optional Accessories

- 6E1C EndocavityConvex probe
- 6I7C Intrarectal Linear probe
- 6C15C、3C20C Micro convex probe
- 2P2F、5P2F 、7P1F  Phased arrayprobe
- USB printer / B/W  / color Video printer
- Puncture rack
- Trolley
- foot switch
- U disk and USB extension line

Dimensions and weight

- Host: size：370mm (width) * 350mm(depth) * 70mm(thickness)
- weight: 5.5kg(with no probe)
- Including package:Size:  465mm(width) ×465mm(depth) × 230mm(thickness)
- weight: 9.5kg(host + 2 probes + power cable + adapter + manual + carton + foam)
